Transformers are one of the most crucial assets in an electrical infrastructure. Period. But, did you know they are also the most overlooked asset?

Well, this isn't good. Not for a utility substation, manufacturing plant, or even a commercial building. The entire power supply relies on how well the transformers are maintained. Yet, transformer failures are among the most common reasons for unplanned power outages, leading to significant losses. That is where transformer maintenance and its services come into the picture.

We understand you may not be well aware of professional transformer testing service and inspection. Fret not, this guide briefly covers all the aspects to help you curate a maintenance schedule that extends your equipment's life.

Before further due, let's get in!

Transformer failure does not happen overnight. It is a result of moisture ingress, thermal stress, accumulated contamination, and aging insulation that has been happening for a while. Even though these activities leave a significant impact, they are not visible to the naked eye until serious damage has occurred.

Routine inspection and testing can help prevent significant concerns before they lead to serious issues. These checks and services matter because:

• Regular inspection and testing ensure early identification of concerns that can escalate into serious issues moving forward. This ensures operational safety and an uninterrupted power supply.
• Early detection can further extend the equipment's lifespan by 10 to 20 years.
• Proactive maintenance schedule limits the chances of unplanned outage recovery or emergency replacement.

Before we look into what is involved in transformer inspection and testing services, let us understand two electrical transformer maintenance approaches - preventive and predictive.

Preventive maintenance

This approach involves a series of scheduled activities to prevent equipment failure. Common activities in this category include inspections, regular oil changes, and cleaning. The aim is to address concerns that can lead to significant problems in the future. This approach helps in preventing sudden breakdowns and maintaining the equipment's operational efficiency.

Predictive maintenance

This approach, unlike the conventional approach, leverages data-driven insights to predict a component's failure. It involves using advanced diagnostics like FRA (Frequency Response Analysis) and DGA (Dissolved Gas Analysis). Predictive maintenance focuses more on targeted interventions, catering to concerns before they lead to failure. All of it minimizes unwanted maintenance activities and ensures reliability, proving to be cost-effective and efficient in the long run.

The key to maintaining your transformer's health is to be thorough with routine maintenance procedures. The significant ones include:

I. Visual inspections

It wouldn't be wrong to call visual & mechanical inspections the first line of defence. Throughout this process, the inspector will check for signs of physical corrosion, damage, and leaks. Additionally, they will check bushings for contamination or cracks to ensure appropriate grounding and tightness of all the electrical connections.

The entire process of visual inspection helps identify crucial environmental or mechanical concerns before electric testing.

II. Oil sampling and analysis

Transformer oil serves as an insulator and coolant. But as oil degrades, it oxidises, absorbs moisture, and can accumulate contaminants, all of which are not visible to the naked eye. That is where regular oil sampling and analysis come into play. It can reveal a lot about what's happening in the transformer's oil tank.

Inspectors base the entire report on several parameters, of which the most important ones include:

• BDV (Dielectric Strength)
• DGA (Dissolved Gas Analysis)
• Moisture content
• Acidity (neutralization number)

Please note that irregularities in these indicators call for a detailed analysis or prompt maintenance.

III. Electrical testing

Electrical testing gives you an insight into what's happening structurally with the transformer. The comprehensive check covers windings, the insulation system, and the overall performance of the unit. The core tests delivering a detailed picture of degradation or concerns include:

• Power Factor (Tan Delta)
• Insulation Resistance (IR)/Megger Testing
• SFRA (Sweep Frequency Response Analysis)

IV. Thermal Imaging

Heat is among the early signs of transformer problems. Several issues, like cooling failures, loose connections, and overloading, appear as heat at its earliest stages. Thermal imaging makes heat visible by using an infrared camera to help identify the following concerns:

• Uneven heat across phases
• Heat near tank joints
• Hot radiator panels
• Hotspots at bushings

The entire process of thermal imaging is safe, quick, and non-invasive. Routine checks can identify problems before they appear in electrical testing.

V. Vibration analysis

The transformer produces a low and steady humming sound. However, changes in vibration or pitch potentially indicate a mechanical concern. That is where vibration analysis helps. It uses sensors to measure certain movements and compare the results with baseline readings.

Different results from the analysis pinpoint specific problems, such as:

• High-frequency vibrations can indicate problems with cooling fans or external parts.
• Increased vibrations can indicate problems with ageing components or core parts.
• Irregular patterns can indicate loose or shifted internal structures.
• Sudden changes can indicate internal faults requiring urgent attention.

Advanced techniques help with detailed analysis and early fault detection. Some of these significant techniques include:

I. FRA (Frequency Response Analysis)

FRA primarily works on core issues, winding deformations, and other mechanical concerns. The technique involves measuring the transformer's response to various frequencies, pinpointing fluctuations that can lead to potential failures. Conducting routine FRA testing ensures the transformer's mechanical integrity.

II. DGA (Dissolved Gas Analysis)

Dissolved Gas Analysis is among the most crucial tests for transformers. DGA helps in the early detection of internal faults, way before they lead to something serious. The checks focus on identifying issues like corona discharge, arcing, and overheating.

It is vital to note that different gases diffused in transformer oil correspond to particular fault types, making this test an important tool for predictive maintenance.

IV. Bushing monitoring and testing

Bushings help maintain safe electrical connections, and their failure can damage the transformer significantly. Its monitoring focuses on changes in power factor and capacitance over time. Noticeable deviations can strongly indicate degradation, or again, highlight the strong need to take action. Similarly, testing of bushings helps identify signs of failure in the early stages to ensure operations stay uninterrupted and smooth.

V. On-line monitoring systems

On-line monitoring systems are becoming popular as a crucial part of transformer maintenance. These systems deliver valuable and real-time insights on several parameters, including electrical performance, gas levels, and temperature.

These systems help identify gradual deviations that can lead to potential failures in the future. Using this system can extend the transformer's life and reduce downtime.

Transformer inspection and testing isn't simply a casual exercise. Instead, it is a strategic investment focusing on safety, uptime, and long-term asset value.

Even though rare, unexpected transformer failures resulting from heat, contamination, moisture, and mechanical stress can lead to huge financial and mental load. By creating a dedicated maintenance schedule, you can identify early-stage problems to reduce unexpected breakdowns.

Overall, we are in a time where transformer downtime can affect revenue and productivity. Thus, maintaining them is essential.

How often should you carry out transformer inspection and testing?

Transformer manufacturers generally recommend carrying out routine visual inspections monthly or quarterly. Whereas detailed testing can be conducted annually. However, it depends on the type of transformer, and some may require frequent checks compared to others.

When should you consider professional transformer testing?

Professional transformer inspection & testing services must be considered for advanced diagnostics and periodic testing. Additionally, you must consider them upon noticing visible signs of abnormal performance.

What are the early signs of transformer failure?

Common early signs of transformer failure include oil discoloration, abnormal heating, increased noise levels, unusual vibrations, and irregular results in electrical or oil tests.

Can modern technology really extend a transformer's life?

Yes. Modern and smart technologies like smart sensors, IoT, and advanced diagnostics can extend a transformer's life by enabling early fault detection, real-time monitoring, and efficient maintenance practices.
